Ubiquiti UniFi Dream Wall (UDW)

£1,021.02

Ubiquiti UniFi Dream Wall (UDW)

The Ubiquiti UniFi Dream Wall is your ultimate all-in-one networking solution. Combining high performance with a sleek, wall-mounted design, it’s perfect for modern homes and small businesses seeking enterprise-grade connectivity.

Ubiquiti UniFi Dream Wall Key Features:

  • Built-in WiFi 6 AP for fast speeds

  • 3.5+ Gbps routing with IDS/IPS

  • (1) 10G SFP+*, (17) GbE RJ45 LAN ports including (4) PoE++, (4) PoE+, and (4) PoE ports

  • (1) 10G SFP+*, (1) 2.5 GbE RJ45 WAN ports

  • Integrated 128 GB SSD & pre-installed 512 GB microSD card

  • High-power PoE switching

  • Full UniFi application support for easy management

  • Wall-mounted design for a clean, modern look

  • Micro SD memory card expansion slot (card needs min 128 GB of storage)

  • User-friendly touchscreen for quick network adjustments

  • Integration with all UniFi OS applications

The UniFi Dream Wall delivers enterprise performance in a compact design. With a Built-in WiFi 6 AP, 3.5+ Gbps routing with IDS/IPS, and (17) GbE RJ45 LAN ports (including PoE options), it effortlessly powers multiple devices. WAN options include 10G SFP+ and 2.5 GbE RJ45 ports for flexibility. Manage it all with a 4.7" touchscreen, 128 GB SSD, and 512 GB microSD card.

Ubiquiti UniFi Dream Wall Technical Specifications

Mechanical

  • Dimensions 549 x 342 x 62 mm (21.6 x 13.5 x 2.4")

  • Weight 10 kg (22 lb)

  • Enclosure materials Polycarbonate, galvanized steel, aluminium alloy

  • Mount material Stainless steel

Hardware

  • Processor specs Quad-Core ARM® Cortex®-A57 at 1.7 GHz

  • System memory 4GB DDR4

  • On-board storage 16 GB eMMCIntegrated 128 GB SSD

  • Expansion slot Micro SD memory card* (optional) *Requires a memory card with at least 128GB of storage.

  • Management interface Ethernet Bluetooth WiFi

  • Networking interfaces (1) WAN: 2.5 GbE RJ45 port(17) LAN: 1 GbE RJ45 ports

  • SFP+ interfaces (1) WAN: 10G SFP+(1) LAN: 10G SFP+

  • PoE interfaces (4) PoE IEEE 802.3af (pair A 1, 2+; 3, 6-)(4) PoE+ IEEE 802.3at (pair A 1, 2+; 3, 6-)(4) PoE++ IEEE 802.3bt(pair A 1, 2+; 3, 6-) (pair B 4, 5+; 7, 8-)

  • LCM display (1) 1.3" touchscreen Start-up animation: start-up in progress Firmware update icon: rmware updating

  • Button Factory-reset

  • Power method Universal AC input 100 to 240VAC, 7A Max, 50/60Hz

  • Power supply (2) Hot-Swappable AC/DC 550W PSU

  • Max. power consumption 532W

  • Max. PoE wattage per port by PSE PoE 802.3af: 15.4WPoE+ 802.3at: 30WPoE++ 802.3bt: 60W

  • Voltage range 802.3af mode 44 to 57V

  • Voltage range 802.3at/bt mode 50 to 57V

  • Mounting Wall mount(included)

  • ESD/EMP protection Air: ± 8 kV, contact: ± 4 kV

  • Operating temperature -10 to 40° C (14 to 104° F)

  • Operating humidity 5 - 95% noncondensing

  • Certications CE, FCC, IC
