Dimensions
442 x 44 x 285 mm (17.4 x 1.7 x 11.2")
Weight
Without mounting brackets: 4.47 kg (9.85 lb)
With mounting brackets: 4.57 kg (11.02 lb)
Enclosure material
SGCC steel
Hardware
Networking interface
(24) 10Gbps RJ45 Ethernet
(2) 25Gbps SFP28
Management interface
Ethernet In-Band
Total non-blocking throughput
290 Gbps
Switching capacity
580 Gbps
Forwarding rate
431.52 Mpps
Max. power consumption
100W
Power method
(1) Universal AC input, 100—240V AC, 2A Max., 50/60 Hz
(1) USP-RPS DC input, 11.5V DC, 8.7A
Power supply
AC/DC, internal, 100W
Services
SMB Layer 3 GbE switch
ESD/EMP protection
Air: ± 16kV, contact: ± 12kV
LCM display
(1) 1.3" LCM color touchscreen
Bootup animation: bootup in progress
Firmware upgrade icon: firmware upgrading
Button
Factory reset
Operating temperature
-5 to 40 C (23 to 104 F)
Operating humidity
10 to 95% noncondensing
Certifications
CE, FCC, IC
Application Requirements
UniFi Network Version 6.1.67 and later
